INDO POWER 17FNX

This crane provides:

A load capacity of 17T, with a maximum operating capacity of 13270 KG. This crane has a four cylinder, water cooled diesel engine with a 60 HP engine, this crane has a boom height of 19.2 m with a horizontal reach of 16.6 m. It has a heavy duty transmission for crane application, sliding mesh spur teeth gearbox, 8 forward and 2 reverse speeds with high and low selector and articulated power steering that is hydraulically controlled through two double acting hydraulic rams.

Safety Features:

Fail-safe brakes on hoist.
Counter balance valve for hose failure protection
Self adjusting hook block.

Make Inquiry

Why Indo Power 17FNX

Crane Features

Cabin With Better Egonomics

Four Side More Visibility Cabin

Heavy Duty Winch

High Ground Clearance

Heavy Drag Duty Winch

Easy for Maitenance

Crane Specifications

Engine
Model & Type	Indo Farm - 3065 DI; Four Cylinder, Water Cooled Diesel Engine Rated power 60 hp max @2200 rpm.
Transmission
Type	Heavy duty transmission for crane application. Sliding mesh Spur teeth gearbox, Eight forward and two reverse speeds with high and low selector.
Axle
Front	Rigidly
Rear	Rigid Mounted with oscillation.
Speed (Top)	30 kmph
Gradeability	40% unladen
Clutch	Single plate, heavy duty dry friction type clutch plate especially designed for crane application.
Drive	2 wheel drive
Steering
Type	Articulated power steering, hydraulically controlled through two double acting hydraulic rams.
Articulation	upto 40°
Turning Radius	8.5 m
Brakes
Front wheel	Fully air operated 'S' cam dual circuit brakes.
Rear wheel	Mechanical disc brakes, actuated through pneumatic brake chamber.
Parking	Air operated fail safe brakes on front wheels.
Tyres
Front	11.00x20 - 16 PR (4 Nos.)
Rear	14.00x25 - 20 PR (2 Nos.)
Wheel Base	4.95 m
Wheel Tracks
Front & Rear	1880 mm (center of twin wheels) / 1630 mm
Boom
Telescoping	4 part boom, 3 part hydraulically powered & fully synchronised. 4th part power extended and manually pinned for safety.
Derricking	Through two double acting cylinders.
Hoist Mechanism
Hoist	Four/Six falls with fail safe brake.
Hydraulic System
Pump	Vane type hydraulic pump.
Control Valve	3/5/6 spool control valve double acting with built in pressure relief valve for trouble free operation.
Electrical System
Type	12V, DC Single battery negative earth.
Overall Dimensions
Length	11375 mm
Width	2450 mm
Height	2945 mm
Operating Weight	13270 Kgs

Download Bronchure

15FNX properties

INDO POWER CRANE

Load capacity:	17T
Boom Height:	19.2 m, 22.2 m with fly zib
Horizontal reach	16.6 m, 19.7 m with fly zib
Engine Power:	60 hp@2200 rpm
